Square Bottle Wrap Around Sticker Labeling Machine

Product Description

N.K Industries is notable manufacturer, supplier & exporter of Variety of state of Art Square Bottle Wrap Around Sticker Labeling machine. The Square bottle Wrap Around Sticker Labelling Machine Model NKSAL-120SQ, is used for Full / Partial Wrap around Labelling on different size of Square bottle / Containers in wide range of industries.

Machine use the latest Servo motor, Fork sensor for Label and fiber optic sensor for the product. It has state of art Combo system which is inclusive of DRP belt & felt system. The machine has been integrated with NO Bottle – No Label system and Emergency stop system.

  • Salient Feature
  • Technical Specification
  • Add On Feature
  • Applicable Industries
  • CGMP Model
  • Machine Construction By AISI 304 Steel
  • Elegantly Designed Label Applicator
  • Reel Mechanism To Place The Roll.
  • No Change Parts Required.
  • Tool Less Guide Rails For Easy Adjustment.
  • Wrap Around Mechanism To Wrap The Label On Square Container.
  • Auto Label Length Detection.
  • Accurate Label Dispensing.
  • Practically A Maintenance Free Machine.
  • Provision For All Type Of Online Batch Coding Like Ink Coder, Cassette Coder, Hot Foil Coder, SS Metal Stereo Box For Printing, Thermal Inkjet Printer

Machine Operating Direction

Left To Right


Up To  120  bottle / Min Depending Upon The Human Efficiency

Type Of Labelling

·   Wrap Around Labelling,

·   Partial Wrap Labelling.

Label Height

10 Mm To 160 Mm

Label Length

12 Mm To Unlimited

Gap Between Two Labels

Min. 5 Mm

Label Roll Dia.

300 Mm Max. Ø

Label Core Dia.

75 Mm To 76 Mm Ø

Power Consumption

1 KW

Electrical Connection

230 Volts, Single Phase, 50 Hz

Height Of Conveyor

Adjustable From 800 To 850 Mm

  • Label Roll Empty - Machine Stop System With Alarm
  • Missing Label In Roll - Machine Stop System With Alarm
  • Special Label Sensor For Sensing Transparent Film Labels Which Does Not Have Any Sensing Mark On It.
  • Toughened Glass Or Acrylic Safety Cabinet For Machine
  • Special Sensing System For Checking Missing Label On Product
  • Vision System For Checking Barcode, Presence Or Absence Of Coding Or Pharma Code On Labels
  • Vision System For Optical Character Recognition (OCR) & Optical Character Verification (OCV)
  • Pharmaceuticals
  • Distilleries & Breweries
  • Cosmetics & Toiletries
  • Lube & Edible Oil
  • Pesticides
  • Food & Ancillaries
