Automatic Round Bottle Sticker Labeling Machine

Product Description

N.K Industries based in Ahmedabad, India is prominent manufacturer, supplier & exporter of range of Sticker Labeling Machine. The Automatic Vertical Self-Adhesive Bottle Sticker Labeling Machine Model NKSAL-120 is used for Full / Partial Wrap around Labeling on different size of round containers like Pet Bottle, Plastic Bottle, Glass Bottle, Wine bottle, Vial. This highly Advanced Round Bottle Sticker Labeling Machine incorporates newest refined Servo controlled Label Dispensing system with outstanding sensing system for Label & container. For Container Sensing, it uses special background Suppression Sensor. The distinctive feature of this machine is “No change parts” required for different diameter of containers & adding up to it tool less adjustment in order to adjust various size containers therefore down time is very less. It’s capable of Labeling up to 120 units per minute depending on Container diameter and label size.

The Automatic Vertical Self-Adhesive Round bottle Sticker Labeling Machine Model NKSAL-120 has elite single point synchronized speed control system. The Inbuilt Automated Label Length detection systems eradicate need for physically feeding & storing of Label Length data in memory & retrieving same every time for change of Label Size & re-starting machine. Thus, result in reducing downtime as well as improving production. The heart of the Bottle Sticker labeling machine is the labelling dispenser head. N.K Industries’s with its long experience in field of machine design has incorporate the special label roll guider, Aluminium sticker label roll holding plate to impart the finest performance in industries.

  • Salient Feature
  • Technical Specification
  • Add On Feature
  • Applicable Industries
Following Are Some Of The Outstanding Inbuilt Features Of Our Round Bottle Sticker Labeling Machine
  • Compact & CGMP Model.
  • Machine Body Is Manufactured Using Matt Finished AISI 304.
  • Machine Top Plate Is Mild Steel With Superior AISI 304 Cladding.
  • Meticulously Designed Superior Slider Label Applicator For Better Label Alignment In Both Vertical And Horizontal Direction.
  • Specially Designed Reel Mechanism To Place Label Roll.
  • Breaking Assembly To Avoid Variation During Releasing Of Roll.
  • No Change Parts Required Either For Change In Round Bottle As Well As Label Sizes.
  • Tool Less Guide Rails For Easy Adjustment.
  • Wrap Around Mechanism To Wrap The Label On Container.
  • Product Conveyor Is Made Using Special Delrin Material.
  • Inbuilt Auto Label Length Detection.
  • Accurate Label Dispensing.
  • 100% Non-Proprietary Electronics & All Electronics CE Certified.
  • Practically A Maintenance Free Machine.
  • Superior Ergonomic Finish Of Machine.
  • Provision For All Type Of Online Batch Coding Like Ink Coder, Cassette Coder, Hot Foil Coder, SS Metal Stereo Box For Printing, Thermal Inkjet Printer.



Machine Operating Direction

Left To Right

Speed

Up To  120  Bottle / Min Depending Upon The Diameter Of Round Container & Label Length.

Type Of Labelling

·   Wrap Around Labelling,

·   Partial Wrap Labelling.

Container Suitability For Labelling

·   Vial Labeling

·   Round Glass Bottle Labeling

·   Round Plastic Bottle Labeling

·   Pet Bottle Labeling

Label Height

10 Mm To 160 Mm

Label Length

12 Mm To Unlimited

Gap Between Two Labels

Min. 5 Mm

Label Roll Dia.

300 Mm Max. Ø

Label Core Dia.

75 Mm To 76 Mm Ø

Container Diameter

20 Mm To 90 Mm Ø

Power Consumption

1 KW

Electrical Connection

230 Volts, Single Phase, 50 Hz

Height Of Conveyor

Adjustable From 800 To 850 Mm

Dimension

1830 Mm (L) X 750 Mm (W) X 1250 Mm (H)

Weight

300 Kgs (Approx.)

Gross Weight

500 Kgs (Approx.)



Round Bottle Sticker Labeling Machine Can Be Equipped With Following Add On Features
  • Label Roll Empty - Machine Stop System With Alarm
  • Missing Label In Roll - Machine Stop System With Alarm
  • Special Label Sensor For Sensing Transparent Film Labels Which Does Not Have Any Sensing Mark On It.
  • Toughened Glass Or Acrylic Safety Cabinet For Machine
  • Tower Light Showing The Machine Status / Operation
  • Special Sensing System For Checking Missing Label On Product
  • Vision System For Checking Barcode, Presence Or Absence Of Coding Or Pharma Code On Labels
  • Vision System For Optical Character Recognition(OCR) & Optical Character Verification (OCV)
  • Online Pneumatically Operated Product Rejection System.
  • Special Sensor For Running Transparent Label.
Round Bottle Sticker Labeling Machine Is Applicable In Following Industries
  • Pharmaceuticals
  • Distilleries & Breweries
  • Cosmetics & Toiletries
  • Lube & Edible Oil
  • Pesticides
  • Food & Ancillaries

Notes:

  • Right Of Technical Enhancement & Modifications Reserved.
  • All Illustrations & Dimensions Are Described For Information Only.
