Automatic Bottle Washing Machine (tunnel Type)

Product Description

The Series of Automatic Bottle washing Machine (Tunnel Type) contain various models & Particular Model can be selected according to output requirement. Output speed is available from 60 bottles per minute to 300 bottles per minute.

The Automatic Bottle washing Machine (Tunnel Type) can work with a variety of round bottle like Glass, PET and HDPE with minimum format parts. These models are equipped with 5 internal washes and 2 outside washes in order to guarantee e complete washing / cleaning. Internal washing done with various entities like Compressed Air, Re-circulated water & DM Water. Outside surface washing done with Re Circulated water & compressed Air.

  • Salient Feature
  • Technical Specification
  • Add On Feature
  • Applicable Industries
  • CGMP & Modular Design.
  • Machine Frame Structure Is Entirely AISI 304.
  • Two Nos Of Emergency Switch Are Fitted At In Feed And Out Feed Side.
  • High Pressure Spray Nozzles Ensure Perfect Wash Of Bottles
  • High Pressure Spray Nozzles Ensure Perfect Wash Of Bottles. Spray Duration Is Electrically Controlled By Magnetic Valve
  • Inbuilt 2 Nos AISI 316L Tanks & Pumps & Are Positioned Suitable For Easy Maintenance.
  • Low Maintenance Cost
  • All Electrical And Brought Out Items Are Of CE Certified.



Model

NKBW-60

NKBW-120

NKBW-240

NKBW-300

Working Direction

Left - Right

Left - Right

Left - Right

Left - Right

Speed

Up To 60 Bottle Per Minute

Up To 120 Bottle Per Minute

Up To 240 Bottle Per Minute

Up To 300 Bottle Per Minute

Conveyor Height

750 ± 50 Mm

750 ± 50 Mm

750 ± 50 Mm

750 ± 50 Mm

Washing Sequence

5 Internal Washes
2 External Washes

5 Internal Washes
2 External Washes

5 Internal Washes
2 External Washes

5 Internal Washes
2 External Washes

No Of Filter

3 Nos Each For Recycled Water , DM Water & Compressed Air

Air Consumption

30 To 50 CFM @  3 To 4 Bar Pressure

Fresh Water Consumption

600 To 900 Ltrs/Hours

DM Water Consumption

600 To 900 Ltrs/Hours

Power Supply

3 KW To  6 KW Depending Upon Model

Electrical Connection

415V, 3 Phase , 50 HZ ,4 Core Wire

Tanks

2 Nos Of AISI 316L Tanks

Input Specifications

30 Ml To 200 Ml Bottles Without Any Major Change Parts.
Can Accommodate Different Sizes Of Bottles With The Help Of Minimal Change Parts.
Special Machines Are Available For Other Size And Type Of Containers On Request



  • PLC With HMI With Audit Trail Facility
  • Drying Station
  • Bottle Lifting Device – At In Feed
  • Turntable At In Feed Section



  • Pharmaceuticals
  • Distilleries & Breweries
  • Cosmetics & Toiletries
  • Lube & Edible Oil
  • Pesticides
  • Food & Ancillaries

Notes:

  • Right Of Technical Enhancement & Modifications Reserved.
  • All Illustrations & Dimensions Are Described For Information Only.
