Bottle Capping Machine

This inventive series of Combi Bottle capping machine is our endevour to various industries in representing cutting edge technology. As name suggest, this machine can carry out ROPP, CRC and Screw capping application. The machine has relatively very easy changeover from ROPP cap to Screw cap to CRC Cap. The Series of Combi bottle capping machine contain a range of models according to number of sealing head like 4 head, 6 head, 8 head. Particular Model can be selected according to output requirement. Output speed of this series is from 100 containers per minute to 220 containers per minute.

The Combi Bottle capping machine can apply Screw Cap , CRC cap ,ROPP Cap on variety of bottle like plastic bottle , glass bottle , Pet bottle , HDPE Bottle with flat and round shape bottle.

  • Salient Feature
  • Technical Specification
  • Add On Feature
  • Applicable Industries
Bottle Capping Machine Has Following State Of Art Salient Featurs:

  • CGMP Model, Compact Model & Modular System.
  • Parts Coming In Contact With Bottle / Screw Cap Are Made Out Of AISI 304, Good Housekeeping
  • Single Motor Synchronizes Conveyor, Star Wheels And Platform Turret.
  • A Special Safety Clutch Devices Are Being Integrated On In Feed & Out Feed Star Wheel System For Stoppage Of Machine In The Event, Vial Is Over Turned.
  • A Special Background Suppression Sensor Stops Machine Automatically In The Event, There Is No Screw Cap In Delivery Chute.
  • Electro-pneumatic No Bottle – No Cap System.
  • Two Cam System Which Controls Cap Pick Up Assembly And Cap Release Assembly
  • New Innovative Magnetic Hysteria Sealing Head For Capping On Bottle With Incorporated Clutch System.
  • Easy Change Over From Screw Cap To Ropp Cap And Vice Versa.
  • Various Cap Feeding Option Available Like Vibrator Feeder System, Mechanical Cap Feeder Orientator Or Water Fall Type Elevator.
  • Fast Format Changeover From One Size Of Container To Other Size Due To Use Of Custom Designed Part.
  • Distinctively Designed Position System Prevents From Cap Being Jammed.
  • 6 Digit Precise Counting Arrangement Helps To Manage Production Process.
  • Outfitted With Emergency Button For Safety Concern.
  • All Electrical & Brought Out Items Are Of CE Certified.

Machine Name

4 Head Combi Bottle Capping Machine

6 Head Combi Bottle Capping Machine

8 Head Combi Bottle Capping Machine

Model

NKSC-150P

NKSC-250P

NKSC-350P

Direction

Left To Right

Left To Right

Left To Right

Production Rate

Up To 100 Bottle Per Minute For 50 Ml Bottle

Up To 120 Bottle Per Minute For 50 Ml Bottle

Up To 180 Bottle Per Minute For 50 Ml Bottle

Electrical Supply

1 HP For Main Drive
0.25 HP For Orientation Unit

1 HP For Main Drive
0.25 HP For Orientation Unit

2 HP For Main Drive
0.50 HP For Orientation Unit

No Of Screw Capping Head

4 Head

6 Head

8 Head

No Of ROPP Head

4 Head

4 Head

4 Head

Auto Cap Pick Up Ratio

≥99.9%

≥99.9%

≥99.9%

Qualified Capping Ratio

≥99.8%

≥99.8%

≥99.8%

Power Requirement

440 V ,3 Phase (4 Wire System ) 50 HZ

440 V ,3 Phase (4 Wire System ) 50 HZ

440 V ,3 Phase (4 Wire System ) 50 HZ

Height Of Conveyor

Adjustable From 800 To 850 Mm

Adjustable From 800 To 850 Mm

Adjustable From 800 To 850 Mm

Bottle Dia

22 Mm To 80 Mm Max

22 Mm To 80 Mm Max

22 Mm To 80 Mm Max

Bottle Height

55 Mm To 200 Mm Max

55 Mm To 200 Mm Max

55 Mm To 200 Mm Max

Screw Cap Dia

22 Mm To 52 Mm Di Cap
(with The Help Of Change Part)

22 Mm To 52 Mm Dia Cap
(with The Help Of Change Part)

22 Mm To 52 Mm Dia Cap
(with The Help Of Change Part)

ROPP Cap Dia

20 Mm To 40 Mm

20 Mm To 40 Mm

20 Mm To 40 Mm

Dimension (L X W X H) Mm

1530 X 812 X 1900

1830 X 812 X 1900

2130 X 915 X 1900

Following Add On Feature Are Avilable For Bottle Capping Machine
  • PLC - HMI Interface
  • Cap Feeder Elevator
  • Automatic Head Up And Down System
  • Toughened Glass Or Acrylic Safety Cabinet For Machine.
Bottle Capping Machine Is Applicable In Following Industrial Segment
  • Pharmaceuticals
  • Distilleries & Breweries
  • Cosmetics & Toiletries
  • Lube & Edible Oil
  • Pesticides
  • Food & Ancillaries
  • Mineral Water
  • Pickle Manufacturing

Notes:

  • Right Of Technical Enhancement & Modifications Reserved
  • All Illustrations & Dimensions Are Described For Information Only
