Automatic Eight Head Vertical Ampoule Filling And Sealing Machine

Product Description

N.K Industries based in Ahmedabad, Gujarat, India is broadly acknowledged as a leading manufacturer & supplier of Automatic Eight head Servo vertical Ampoule filling and sealing machine which is its endeavour to the highest quality of technology in injectable SVP (Small Volume Parenteral) segment. Due to the Advance manufacturing technique, our machine assures accurate filling, lowest breakage ratio & superior sealing. The Vertical Ampoule filling and sealing machine can work with 1 ml to 10 ml ampoule and has the capability to deliver the higher output around 280 to 300 Ampoules/ minute for 1ml and 2 ml ampoule.

The Exceptional features of the machine are “No Ampoule – No Filling system”, “Fine volume setting of individual syringe.

  • Salient Feature
  • Technical Specification
  • Add On Feature
  • Applicable Industries

Automatic Eight Head Vertical Ampoule Filling And Sealing Machine Is Equipped With Following Highly Advanced Features:

  • CGMP Model.
  • Imported Gear Box And Gear Motor.
  • As A Optional In Feed Wire Mesh Conveyor For Transfer Of Ampoules To The Filling Operation (Can Be Attached Online With Tunnel)
  • Machine Frame Made Using AISI 304.
  • All Contact Parts With Liquid Made Using AISI 316L.
  • Foaming & Spillage Is Avoided Due To Diving Nozzles.
  • Output Speed Of 300 Ampoules/Min For 2 Ml. Ampoule
  • Machine Direction From Right To Left.
  • Elegantly Designed Aluminium Rack To Transfer The Ampoules To The Filling And Sealing Station.
  • Precisely Centering Of Ampoules Neck While Passing Through The Various Stage Of Operation Like Gas Flushing, Filling & Sealing Of Ampoules.
  • Pre & Post Gasing Unit
  • PLC System With Touch Screen HMI (Make: Delta, Taiwan)
  • Individual Adjustment Of Volume For Individual Syringes Through HMI. No Manual Tuning Required
  • S.S. Pipe Structure With Toughened Glass Cabinet
  • Flow Meter For LPG, Oxygen & Nitrogen
  • Ampoule Discharge With Pusher Arrangement
  • Volume Setting Can Be Adjusted From HMI, As Machine Filling Unit Is Controlled Through Individual Servo Motor
  • Can Fill Up To 10 Ml (With Minimum Change Part)
  • Outfitted With Emergency Button For Safety Concern.
  • Heat Extraction Unit Consisting Of The Suction Blower Will Be Provided. Ducting To Be Arranged Of Uniform Size.
  • All Electrical & Brought Out Items Are Of CE Certified





Model

NAFS-240V

Name

Eight Head Vertical Ampoule Filling Sealing & Machine

Output

300 Ampoule / Minute Depending Upon Ampoule Diameter

Filling Technology

Advanced Volumetric Piston Pump Type

Filling Accuracy

±1 %

Filling Range

1 Ml To 10 Ml

No Of Filling Head

8 Head (Vertical)

Gas

LPG & Oxygen (Mixture)

Power Requirement

230 V ,single Phase , 50 HZ

Electrical Supply

2 HP

Ampoule Size

1 Ml To 10 Ml Ampoule

Net Weight

500 KG

Dimension
(L X W X H) Mm

3000 X 1200 X 1300

  • Toughened Glass Or Acrylic Safety Cabinet For Machine.
  • Wire Woven Mesh Conveyor For Connection With Sterilization Tunnel
  • Pharmaceuticals
  • Injectable
  • Small Volume Parenteral

Notes:

  • Right Of Technical Enhancement & Modifications Reserved
  • All Illustrations & Dimensions Are Described For Information Only
