Semi Automatic Ropp Capping Machine

Product Description

Semi Automatic ROPP Capping Machine

N.K Industries, based in Ahmedabad, Gujarat is a pioneer manufacturer & Exporter of State of Art Semi automatic ROPP Capping machine. Our Semi automatic ROPP Capping machine Model NKCS- 50R is appropriate Engineering solution for startup industries where production demand is low & qualitative ROPP Sealing / capping required. The machine can deliver 30 Bottle per minute output depending upon operator competence. Qualitative ROPP Capping result due to use of motorized sealing head.

Semi Automatic ROPP Capping machine can work with wide shaped of container like Round, Square, and Triangular with minimum change part. Machine speed can be adjusted due to the Use of Sensor less vector control Variable frequency drive.

The Semi Automatic ROPP capping machine is precision built on sturdy welded AISI 304 frame completely enclose in stainless steel sheet and doors are provided to facilitate the servicing of machine. Machine is having motorized rotating head mechanism which is constantly moving up and down. Require manually feeding & unloading container, where the body and the neck of the container are positioned below the rotating head and sealing head is performing perfect operation of capping with uniform torque.

  • Salient Feature
  • Technical Specification
  • Add On Feature
  • Applicable Industries
Semi Automatic ROPP Capping Machine Is Equipped With The Following State Of Art Features:
  • CGMP Model.
  • Compact & Multipurpose Unit.
  • Easy Operating Interface As Operating Panel Mounted At Front Side Of Machine.
  • Motorized Sealing Head.
  • No Change Parts Require For Different Container Diameter.
  • Low Power Consumptions.
  • Adjustable Bottle Height Gauge Provided For Easy & Quick Setting.
  • Sealing Pressure Can Be Varied To Suit Different Size Of ROPP Caps.
  • Powered Using The High Perfoamnce Worm Gear Box And Gear Motor.



Model

NKCS -50R

Type Of Capping

ROPP Type Capping

Output/Hour*

30 -40 Bottle Per Minute Depending Upon Operator Efficiency

Number Of ROPP Capping Head

1 Nos.

Power Consumption (KW)

1 KW

Electrical Connection

230 V , Single Phase , 50 HZ

ROPP Cap Diameter (mm)

18 Mm To 32 Mm (With Change Part)

Container Diameter (mm)

Ø 22 Mm To Ø 100 Mm

Container Height   (mm)

58 Mm To 240 Mm

Overall Dimension

1000 Mm (L) X 720 Mm (W) X 1400 (H) Approx.

Net Weight

200 Kgs. Approx.

Gross Weight

350 Kgs. Approx.

Change Parts Required

Cap Die If Cap Diameter Change.



  • Screw Capping Attachment To Run Screw Cap.
Following Industries Are Produly Using Our State Of Art Economical Semi Automatic ROPP Capping Machine.
  • Pharmaceutical
  • Beverages
  • Wine
  • Distilleries



Notes:

  • Right Of Technical Enhancement & Modifications Reserved.
  • All Illustrations & Dimensions Are Described For Information Only.
