Shrink Sleeve Labeling Machine

Product Description

Shrink Sleeve Labeling machine

N.K Industries is pioneer manufacturer , supplier & Exporter of range of Shrink Sleeve Labeling machine Model NKSSA-100 / 200 / 300 which are used to apply the Sleeve on the body of container. The sleeve film is durable, abrasion resistant and waterproof & full body sleeve allows for higher degree of creativity with graphics, multiple Colour Schemes which in turn useful to increase the brand awareness in your business.

The Outstanding Feature of Shrink Sleeve Labeling machine is “No Bottle – No Sleeve system” & very easy interlocking with conventional Shrink tunnel at downstream side.

  • Salient Feature
  • Technical Specification
  • Applicable Industries
Our Versatile Shrink Sleeve Labeling Machine Is Equipped With Following Features
  • Complete SS 304 Construction
  • Fully Automatic Operation.
  • No Bottle - No Sleeve-Feature (Eliminates Wastage).
  • Can Handle Round Glass / Plastic Bottles.
  • Speed Of 80 To 300 Bottles/min. Depending On The Cut Length Of The Sleeve.
  • Servo Motors For More Accuracy.
  • Fitted With Digital PLC Control.
  • Height Adjustments To Suit Height Variant Bottles.
  • Eye Mark Sensor For Accurate Cutting In Printed Sleeves.
  • VFD Used To Increase Or Decrease The Speed Wherever Necessary.
  • Can Easily Be Synchronized With A Tunnel.
  • Very Easy Change Over.
  • All Electronics And Electrical Are Of CE Certified.

Model

NKSSA -100

NKSSA-200

NKSSA-300

Speed

80 To 100 BPM

180 To 200 BPM

280to 300 BPM

* Depending Upon The Container Size

Operating Direction

Left To Right

Container Size

Round Container

Sleeve Size

50 – 200 Mm (Length)

50 – 100 Mm (width)

Sleeve Thickness

Minimum 40 Micron Thickness

Conveyor Size

100 Mm(W) X 2000 (L) X 850 +100 Mm Adj. Legs (H)

Electrical Rating

·    1 Phase Electric Supply,230 ± 5 V AC, 50Hz Earth & N

·    Stabilizer Will Be Provided By You To Avoid Voltage Fluctuation.

·    All Civil Work Where The Machines Are To Be Installed.

Air Supply

6-8 Bar Continuous Air Pressure With Air Filter And Air Regulator

Floor Space Requirement

Approximately 1mtr From All Sides Of The Machine. Hence, Clearance Of 1mtr Should Be Added To The Actual Size Of The Machine.

Operator Requirement

1 Skilled/ Semi-Skilled

Essential

·    Container Should Be Of Good Quality.

·    Operator Should Understand The Working Of The Machine Properly.

  • Pharmaceuticals
  • Distilleries & Breweries
  • Cosmetics & Toiletries
  • Lube & Edible Oil
  • Pesticides
  • Food & Ancillaries

Note:

  • Right Of Technical Enhancement & Modifications Reserved.
  • All Illustrations & Dimensions Are Described For Information Only.
