Automatic Linear Vial Washing Machine (tunnel Type)

Product Description

N.K Industries representing Series of Automatic Linear Vial washing Machine (Tunnel Type) are specifically dedicated to cleansing of injectable vials, resulting from specific research into the decontamination of containers for injectable use. The Series of Automatic Linear Vial washing Machine (Tunnel Type) contain various models & Particular Model can be selected according to output requirement. Output speed is available from 60 to 400 vials per minute.

The Automatic vial washing Machine (Tunnel Type) can work with a variety of vial range from 2ml to 100 ml vial with minimum format parts. These models are equipped with 8 internal washes and 2 outside washes in order to guarantee e complete washing / cleaning. Internal washing done with various entities like Compressed Air, Re-circulated water, Fresh DM Water & Fresh WFI water. Outside surface washing done with Re Circulated water & Fresh WFI water.Washing sequence can be modified as per the customer requirement.

  • Salient Feature
  • Technical Specification
  • Add On Feature
  • Applicable Industries
  • CGMP & Modular Design.
  • Machine Frame Structure Is Entirely AISI 304.
  • Easy Downstream Integration With Sterilizing Tunnel
  • Emergency Switch Are Fitted At In Feed And Out Feed Side.
  • Washing Chamber Having Various Spray Zones Of Various Entity Like Air And WFI Water & Spray Duration Is Electrically Controlled By Magnetic Valve.
  • PENETRATING TYPE NOZZLE For Water And Air Spraying.
  • Inbuilt 2 Nos AISI 316L Tanks & Pumps.
  • Low Maintenance.
  • All Electrical And Brought Out Items Are Of CE Certified.

AUTOMATIC LINEAR VIAL WASHING MACHINE (TUNNEL TYPE)

Model

NKVW-60

NKVW-120

NKVW-240

NKVW-300

NKVW-400

Working Direction

Left - Right

Left - Right

Left - Right

Left - Right

Left - Right

Speed

Up To 60 Vial Per Minute

Up To 120 Vial Per Minute

Up To 240 Vial Per Minute

Up To 300 Vial Per Minute

Up To 400 Vial Per Minute

Conveyor Height

750 ± 50 Mm

750 ± 50 Mm

750 ± 50 Mm

750 ± 50 Mm

750 ± 50 Mm

Washing Sequence

10 Internal Washes
2 External Washes

10 Internal Washes
2 External Washes

10 Internal Washes
2 External Washes

10 Internal Washes
2 External Washes

10 Internal Washes
2 External Washes

No Of Filter

Filter For Recycled Water , DM Water & Compressed Air And WFI Water

Air Consumption

10 - 30 CFM Depending Upon The Machine Model & Vial Size

Fresh Water Consumption

100 To 350 LPM Depending Upon The Model & Vial Size

Power Supply

3 To 5 HP, 440 V, 3 Phase, 50 Hz

Electrical Connection

415V, 3 Phase , 50 HZ ,4 Core Wire

Tanks

2 Nos Of AISI 316L Tanks

Input Specifications

5 To 30 Ml Without Any Change Parts
Additional Change Parts Will Be Required For 2 Ml & 50 - 100 Ml Vials.

  • PLC - HMI Interface
  • Ultrasonic Wash Available Upon The Request.
  • Water Recycling Arrangement
  • Pharmaceuticals
  • Injectable

Notes:

  • Right Of Technical Enhancement & Modifications Reserved.
  • All Illustrations & Dimensions Are Described For Information Only.
