Automatic Double Head Volumetric Liquid Filling Machine



Automatic Double head Volumetric Bottle Liquid filling machine Model NKLF-40 is suitable for Round Bottle, Flat shape Bottles & Glass Vials with maximum speed of 30 containers per minute. It works on volumetric principle where syringes suck liquid from tank and fill it in container. The output depends upon the various factors like nature of Liquids, Neck Diameter or Vial/Bottle and Fill Volume. For Container Sensing, it uses special background Suppression Sensor. The distinctive feature of this machine is “No bottle- No Filling”

Machine structure is made using AISI 304 and all contact parts with liquid are of AISI 316L. Machine is capable to fill from 5 ml to 500 ml in single stroke and above 500 ml can be handled with double stroke.

  • Quite A Compact & Modular Design
  • cGMP Model.
  • Machine Frame Made Using AISI 304.
  • All Contact Parts With Liquid Made Using AISI 316L.
  • Tool Less Guide Rails For Easy Adjustment For Container.
  • Fill Volume Can Be Adjusted With The Help Of Adjustable Eccentricity Of Ram Shaft.
  • Wide Range Of Syringe Selection Available To Fill From 5 Ml To 1000 Ml
  • Self Centring Device To Take Care Of Non Concentricity Of Container To Certain Extant.
  • Foaming & Spillage Is Avoided Due To Diving Nozzles.
  • Long Liquid Collection Tray With Outlet Below Conveyor To Safeguards Transmission Assemblies.
  • No Bottle – No Filling Arrangement
  • Buffer Tank Of 150 Litre Capacities With Stirrer.
  • Toughened Glass Or Acrylic Safety Cabinet For Machine
  • Tower Light Showing The Machine Status / Operation
  • PLC – HMI Interface
  • Celling Suspended Laminar Air Flow Hood / Embedded Vertical Laminar Air Flow Hood

Model

NKLF-40

Output

30 Container Per Minute

Filling Accuracy

±1 %

Filling Range

2 Ml To 500ml
(Above 500ml Help Of Stroke System)

No Of Filling Head

2 Head

Power Requirement

230 V ,single Phase , 50 HZ

Electrical Supply

1 HP

Container Diameter

16 Mm To 100 Mm (With The Help Of Change Part)

Container Height

Up To 100 Mm

Net Weight

200 KG

Dimension
(L X W X H) Mm

1530 X 850 X 1700

  • Pharmaceuticals
  • Distilleries & Breweries
  • Cosmetics & Toiletries
  • Lube & Edible Oil
  • Pesticides
  • Food & Ancillaries

Notes:

  • Right Of Technical Enhancement & Modifications Reserved.
  • All Illustrations & Dimensions Are Described For Information Only.
